Running Django-Neomodel within a Docker Container

COO of SilverLogic

May 26, 2021

2 min read

Here’s your quickstart guide for posterity, using the example in Django-Neomodel.

A Neomodel community member asked about how to run Django Neomodel (a Neomodel plugin for Django) within a Docker container. So let’s show how to do it.

Haven’t tried out Django-Neomodel yet? Start here. Neo4j for Django Developers

Local Setup — Example

Prerequisites:

An updated version of Docker
Django Neomodel

The Django-Neomodel repository comes with a Docker example. If you’re just getting started with Docker, this may be a good place to start. From the root of the Django-Neomodel repo, go to the tests directory:

cd tests/

Run the Docker Command (make sure your Docker service is running and up to date).

docker-compose up

Verify the Django admin is running: https://localhost:8000/admin/ Verify Neo4j Browser is running: https://localhost:7474/browser/ You’ll be then able to log in with the test credentials admin / 1234.

Under the Hood

Dockerfile

The Dockerfile collects the commands Docker will be using to create your environment.

FROM python:3
WORKDIR /usr/src/app
COPY ./tests/requirements.txt ./
RUN pip install — no-cache-dir -r requirements.txt
COPY .. .
RUN chmod +x ./tests/docker-entrypoint.sh
CMD [“./tests/docker-entrypoint.sh” ]

docker-compose.yml

docker-compose.yml is where you’ll configure the ports you’ll be using to communicate with your Neo4j database. docker-compose.yml :

version: ‘3’
services:
    backend:
        build:
            context: ../
            dockerfile: ./tests/Dockerfile
        command: ‘/bin/bash -c “chmod +x /usr/src/app/tests/docker-entrypoint.sh && /usr/src/app/tests/docker-entrypoint.sh”’
        volumes:
          - ..:/usr/src/app
        ports:
          - “8000:8000”
        expose:
          - 8000
        depends_on:
          - neo4j_db
        links:
          - neo4j_db
        environment:
          - NEO4J_BOLT_URL=bolt://neo4j:foobar@neo4j_db:7687
          - DJANGO_SETTINGS_MODULE=settings

neo4j_db:
        image: neo4j:4.2-enterprise
        ports:
          - “7474:7474”
          - “7687:7687”
        expose:
          - 7474
          - 7687
        volumes:
          - db:/data/dbms
        environment:
          - NEO4J_AUTH=neo4j/foobar
          - NEO4J_ACCEPT_LICENSE_AGREEMENT=yes
          - dbms.connector.bolt.listen_address=:7687
          - dbms.connector.bolt.advertised_address=:7687

volumes:
    db:

docker-entrypoint.sh

docker-entrypoint.sh is where you’ll configure the python/Django portion of your app. You’ll add your DJANGO_SUPERUSER_USERAME and other Django-related environment variables here. docker-entrypoint.sh :

#!/bin/bash -xe
cd tests
python -c <<EOF |
from django.db import IntegrityError
try:
    python manage.py install_labels
except IntegrityError:
    print(“Already installed”)
EOF

python manage.py migrate # Apply database migrations
if [ “$DJANGO_SUPERUSER_USERNAME” ]
then
    python manage.py createsuperuser
        — noinput
        — username $DJANGO_SUPERUSER_USERNAME
        — email $DJANGO_SUPERUSER_EMAIL
fi

$@
python manage.py runserver 0.0.0.0:8000

Resources

Running Django-Neomodel within a Docker Container was originally published in Neo4j Developer Blog on Medium, where people are continuing the conversation by highlighting and responding to this story.
